The product adopts piezoelectric type acceleration sensor and is suitable for measurement of conventional vibration of mechanical equipment. It can measure the vibration speed, acceleration, displacement and is widely used in mechanical manufacturing, electric power, chemical engineering, space flight and aviation and other fieldsification: Model: HT-1201 Color: Grey Vibration acquisition: piezoceramic accelerometer (shearing type ) LCD display: three and a half digit display Measurement range: Acceleration: 0.1-199.9m/s2 (peak value) Speed: 0.1-199.9mm/s (effective value) Displacement: 0.001-1.999mm (effective value) Measurement accuracy: ±(5%+2digits) Frequency range: Acceleration: 15Hz – 1KHz (LO), 1KHz – 10KHz (HI) Speed: 15Hz – 1KHz (LO) Displacement: 15Hz – 1KHz (LO) Temperature measurement 0℃ – 60℃ Temperature accuracy: ±2℃ Automatic power-off time: 4 minutes Power supply: 3 x AA battery (NOT included) Operation temperature: 0℃ – 45℃ Operation humidity: 20%RH – 90%RH(No condensation) Storage temperature: -20℃ – 60℃ Size: Approx. 150*70*32mm/5.9*2.8*1.
Acceleration Sensor Gauge Digital Precision Split Type Vibration Meter Compact design anti-slip rubber handle Vibrometer for lab with manual calibration knob
$273.99
- 【Wide measurement range】Wide measurement range of acceleration: 0.1~199.9m/s2 peak. Speed: 0.1-199.9mm/s. Displacement: 0.001-1.999mm
- 【Piezoelectric acceleration transducer】Adopts piezoelectric acceleration transducer transfer the vibration signal in to electrical signal, analyze the input signals, and show the vibration speed, acceleration, displacement
- 【℃ and ℉】It can measure the environment temperature with 2 temperature units (℃ and ℉)
- 【LCD display】LCD displays measurement result and conditions directly
- 【Widely used】Widely used in mechanical manufacturing, electric power, chemical engineering, space flight and aviation and other fields
In stock
Additional information
| Weight | 0.77 kg |
|---|---|
| brand | Oumefar |
| dimensions | 15.2 x 7.5 x 3.2 cm; 744 Grams |
