ADWITS USB 3.1 Gen 2 Type A and C Combo to M.2 2230/2242/2260/2280 High-Performance PCIe NVMe SSD Adapter
Ideal solution for portable storage of heavy files, 4K movies, 3D games, RAW media
Support UEFI USB booting
NOTICE
To make this enclosure a bootable drive, please use your OS tools to make it. For example MediaCreationTool for WIN 10, Disk Utility for Mac OS
If your NVMe M.2 SSD is not recognized correctly and not useful, please rebuild the SSD partition table by “diskpart” command under windows, and “Disk Utility” under Mac OS
To make a clone of your previous NVMe SSD, please beware that the Physical Sector Size might be different. And your cloning software might not be able to accept this conflict of physical sector difference and cause unsuccessful clone. You need to try different cloning software or use your NVMe SSD tool to change the physical sector size. For example Intel SSD Data Center Tool for intel NVMe SSD
This adapter only supports M.2 NVME SSD. DO NOT support M.2 SATA SSD and M.2 AHCI SSD
Features
Master chipset: Jmicro JMS583 USB 3.1 Gen 2 to PCIe Gen3x2 Bridge Controller
Complies with PCI Express Base Specification Revision 3.1a
Complies with NVM Express 1.3
Complies with USB 3.1 Gen 1 and Gen 2 Specification, USB Mass Storage Class, Bulk-Only Transport Specification (Revision 1.0)
Complies with USB Attached SCSI Protocol (UASP) Specification (Revision 4)
Compatiable with USB2.0/USB 3.1 Gen 1/2, supports USB Super-Speed/High-Speed/Full-Speed Operation
Supports TRIM to the SSD
Package list
ADWITS USB 3.1 Gen 2 Type A and C Combo to PCIe NVME Adapter x1
ADWITS USB 3.1 Gen 2 Type A and C Combo to M.2 2230/2242/2260/2280 High-Performance PCIe NVMe SSD Adapter, with JMS583 Bridge Controller Compatible 960 970 EVO PRO Solid State Drive
$62.99
- Make sure this fits by entering your model number.
- Perfectly fit with 22*30mm, 22*42mm, 22*60mm, 22*80mm PCIe NVMe M.2 SSD, no cables needed
- Only works with PCIe NVMe M.2 SSD, doesn’t support any other SSD like SATA SSD, AHCI SSD, mSATA SSD. And you must initialize your NVMe SSD to use it
- Compatible For Windows 8 / 8.1 / 10 and Mac OS 10.1 and above, Linux
- Using JMS583 USB3.1 Gen 2 to PCIe Gen3x2 bridge controller, supporting stable transfer speed up to USB3.1 Gen 2 SuperSpeed+ 10Gbps, 1250MBps (theoretical)
- Superior design with usb 3.1 Gen 2 type A and type C ports, direct connection with computer, doesn’t need any cable or USB-C adapter
In stock
Additional information
| Weight | 0.02 kg |
|---|---|
| brand | Adwits |
| dimensions | 12.8 x 7.8 x 2.4 cm; 20 Grams |
