Technical features: Rated voltage: 250 V AC. Rated current: 16 A. Switching current: 10 AX. Operating temperature: -40 °C to 30 °C. Colour: grey/light grey matt. Main design line Berker W.1 Protection class: IP55. With full-surface seal on the back of the housing for rear cable entry and plaster compensation. With hinged lid, can be manually locked into place. For vertical mounting. Toggle switch and socket can be connected separately. With an introduction for 2 cables and an introduction for cable or pipe. With plug-in terminals. Hinged lid springs made of rust-proof stainless steel, pins of the quick release from ZAMAK. Energy. – Rated voltage: 250 V. – Rated current: 16 A. Design – Product colour: grey. – Case material: plastic. – Frame (area): yes. – On/Off Switch: Yes – International protection class (IP code): IP55. Functions: Socket type: F type – Socket quantity: 1. – Supported plug types: CEE 7/4. – Operating temperature range: -40 – 30 °C.
Berker AP Combination 47803515 Light Grey
HKD839.58
- Make sure this fits by entering your model number.
- Design of the switch = two-way switch
- Operating mode = rocker / button
- Mounting direction: vertical
- Attachment type: attachment with screws
- With lighting: no
In stock
Additional information
| Weight | 0.12 kg |
|---|---|
| dimensions | 15.01 x 8 x 8 cm; 80 Grams |
