BW 4-ports 10/100M Desktop PoE Switch 15.4W per port

BW 4-ports 10/100M Desktop PoE Switch provides the seamless network connection. It integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities, For cost saving and flexible using of PoE power provision, BW5000 series provides PoE power injector function which is able to drive 4 IEEE 802.3af compliant powered devices. Besides, the switch also provides a simple, cost-effective, and highly reliable network connection for data as well as power. Easy Cabling InstallationWith data and power over Ethernet from one unit, the BW5000 series shall reduce cables and eliminates the need for dedicated electrical outlets on the wall, ceiling or any unreachable place. A wire carries both data and power lowering the installation costs, simplifying the installation effort and eliminating the need for electricians or extension cords5004P, 4 ports PoE Switch,10/100Mbps.15.4WSpecification:Input Voltage: 48V DCNetwork standards: IEEE802.3i 10 BASE-T, IEEE802.3i 100 BASE-TX, IEEE802.3x flow controlIEEE802.3af /IEEE802.3at;PoE power: 15.4/25.5W per port; Wiring: Data & Power provided over pairs 12&36 and 45(+) & 78(-)Cable: UTP cat.5 or higher;Processing types:Store-and forward;Half-duplex back pressure and IEEE802.3X full-duplex flow controlPower supply: Total power consumption: 70W/110W; Total PoE power budget: 60W/120W; Bandwidth: 1.6GbpsNetwork delay(100 to100M bps):less than 2msBuffer Memory:96KBAddress Database Size: 1000MAC/systemLED indicatorSystem: Power,PoE max. powerPer port: Link,speed,PoE active, PoE errorWorking Tem: 0℃-40℃Storage Tem:-10℃-70℃Operatig Humidity:20％-85％,Non-condensingLED indicatorSystem: Power,PoE max. power 110WPer port: Link,speed,PoE active, PoE error
