Setting:
1. Set the camera to your car’s license plate area.
2. Adjust the camera lens to its best position.
3. Connect the power wire (red and black) to light power wires of your car.
4. Connect the video (yellow) to the display.
It is suitable for 12V automotive electrical system and cannot be installed on 24V electrical models.
Please use the supplied dedicated line for the connection between the components.
During installation, care should be taken to prevent flattening, puncturing, cutting, and extension of the connecting wires.
Please install and maintain the system when the power is off.
Specifications:
Images Sensors: 1/4CMOS
Chip: color CCD Signal System: NTSC/PAL Horizontal Resolution (TV lines): 600 TV lines Effective Pixels: 720*480pixels Lens viewing angle: 140 degrees Horizontal viewing angle: 115degrees IP Rating: IP67 IP68 AGC & BLC: Auto Video Output: 1.0Vp-p, 75 ohm Current Consumption: 130-150 mA S/N ratio: Better than 48dB (AGC-OFF) Minimum Illumination: 0.1Lux/F1.2 Shutter speed: 1/50(1/60)-1/100,000sec Power Supply (DC): 12V Operating Temperature (Deg.C): -30 to +85 Storage Temperature (Deg.C): -40 to +85
Packing Included:
1 x Car reversing camera
1 x Video Cable
1 x Power Cable
