Dechengbao Hexagon Crimper Plier Set, 0.25-6mm²/AWG23-10 Self-Adjustable Ratchet Wire Crimping Tool with 1200PCS Wire Terminal Crimp Connectors and Wire End Ferrules

Please choose the appropriate terminals with the suitable sleeves, then you can make a perfect crimping. After sales services: Respond your email within 24hours. You deserves the best. HSC8 6-6 Hexagonal Profile Crimp Tool Feature: 1 solder-free electrical connections 2ral loading of the end sleeves (ferrules) into the tool 3le handling as a result of self-adjustment to the size of the end sleeve (ferrule) 4e tools have been set precisely (calibrated) in the factory 5mum transmission of force due to lever action for fatigue-reduced operation 6 operation comfort thanks to handy shape and low weight Specifications: Model: Hexagonal Profile Crimp Tool Material: Nylon & copper alloy Capacities mm²: 0,25 ~ 10 mm² AWG: 23 ~ 10 Overall length: 175mm Range of Application: Wire-end Ferrules Terminal detail: E0508 22AWG (White) x 200pcs L:14 F:8 B:6 W:2.6 C:1.0 D:1.3 E7508 20AWG (Gray) x 200pcs L:14.6 F:8 B:6.4 W:2.8 C:1.2 D:1.5 E1008 18AWG (Red) x 200pcs L:14.6 F:8 B:6.4 W:3 C:1.4 D:1.7 E1508 16AWG (Black) x 250pcs L:14.6 F:8 B:6.4 W:3.5 C:1.7 D:2.0 E2508 14AWG (Blue) x 250pcs L:15.2 F:8 B:7.2 W:4 C:2.3 D:2.6 E4009 12AWG (Gray) x 50pcs L:16.5 F:9 B:7.5 W:4.4 C:2.8 D:3.2 E6012 10AWG (Yellow) x 25pcs L:20 F:12 B:8 W:6.3 C:3.5 D:3.9 E10-12 7AWG (Red) x 25pcs L:21.5 F:12 B:9.5 W:7.6 C:4.5 D:4.9 Package Included: 1 x HSC8 6-6 Hexagonal Crimper 1200PCS x Crimp Connectors How to care for your crimp tools it is recommended that operator of the tool be made aware of ,and responsible for ,following these maintenance steps: 1ve dust ,moisture ,and other contaminants with a clean brush ,or a soft lint free cloth ,do not use objects that could damage the tool 2 certain that all pins , pivot points ,and bearing surfaces are protected with a thin coat of any good SAE no 20 of any good motor oil ,do no oil excessively
