ed Operating Voltage : AC 200~250V
Poles: 1P
Rated Current: 60A
Working Frequency: 50/60Hz
breaking capacity: 4 kA Ics=Icu
Trip Curve: C
Mechanical Life: 10,000 times
Electrical Life: 4,000 times
Installation Method: 35MM DIN Rail
Standard: IEC60898 / GB10936
Operating Temperature: -30℃ to +70℃
Operating Altitude: 2000 Meter
Circuit Breaker Purchase Instructions
The cause of the circuit breaker fire
1. The current is high and the cable is thin, and the cable heats up and causes a fire
2. Poor contact, the screws of the circuit breaker are not tightened, causing the screw part of the circuit breaker to heat up and catch fire (90% of the fire causes)
Note: Be sure to tighten the screws — important!!!
3. The quality of circuit breakers is poor. Our company selects A-level standard materials and flame-retardant shells for production. Each product is tested, and the quality pass rate reaches 99.5%.
4. Dust enters, humid environment; the circuit breaker is not waterproof and dustproof, try to use it in a waterproof box.
Note：If you find that the screw part of the circuit breaker is burned, 99% of it is because the screw is not tightened
How to choose the current of the circuit breaker
The current of the circuit breaker needs to be 20% larger than the working current. If the working current is 20A, Please choose 25A circuit breaker. If choose 20A, the circuit will trip and power off
Part number:- DHO-DZ47-1P-63A
Item Weight:- 200 g
Package Dimensions:- 9 x 8 x 4 cm; 200 g
Item model number:- DZ47 63
Colour:- AC200V-400V 1P
Shape:- AC200V-400V 1P
Plug profile:- DIN Rail Mount
Included components:- Circuit Breaker*2;Din rail mount*1;terminal*4
Batteries included?:- No
Batteries Required?:- No
Date First Available:- 18 Mar. 2022
Brand:- DIHOOL
Current rating:- 63 Amps
Circuit breaker type:- Standard
Mounting type:- DIN Rail Mount
Number of poles:- 1
