– Up to 2 megapixel high resolution – Max. 1920 × 1080 @30fps – 2.8 mm/4 mm/6 mm/8 mm/12 mm fixed lens, optional – Ultra-low light – H.265, H.265+, H.264+, H.264 – 120dB Wide Dynamic Range – 3D Digital Noise Reduction – DC12V & PoE (802.3af) – IR range: up to 30 m – Support on-board storage, up to 128 GB – IP67, IK10 Audio -Voice codecs: MP2L2, G.711, G.722.1, G.726 Ports & interfaces -Connectivity technology: Wired -Ethernet LAN (RJ-45) ports: 1 -Interface: RJ-45 Lens system -Fixed focal length: 2.8 mm Weight & dimensions -Height: 82.4 mm -Diameter: 11.1 cm -Weight: 500 g -Package width: 134 mm -Package depth: 134 mm -Package height: 108 mm Power -Power source type: PoE -Power over Ethernet (PoE): Y -DC output voltage: 12 -Power consumption (max): 5 W -Power consumption (Power over Ethernet (PoE)): 6.5 W Operational conditions -Operating temperature (T-T): -30 – 60 °C Technical details -Lens mount interface: M12 -Removable IR-cut filter: Y Networking -Ethernet LAN: Y -Wi-Fi: N -Ethernet interface type: Fast Ethernet -Cabling technology: 10/100Base-T(X) -Networking standards: IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u -Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 -3G: N -4G: N -Quality of Service (QoS) support: Y Video -Maximum resolution: 1920 x 1080 pixels -Total megapixels: 2 MP -Video compression formats: H.264, H.264+, H.265, H.265+, M-JPEG -Supported graphics resolutions: 352 x 240, 352 x 288, 640 x 360, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) -Analog signal format system: NTSC, PAL -Noise reduction: Y
Additional information
| Weight | 0.7400 kg |
|---|---|
| ean | 6954273637828 |
| brand | HIKVISION |
| mpn | DS-2CD2125FWD-I(2.8MM) |
