Specification:
Clamp Body Length: 130mm
Clamp Body Width: 130mm
Clamp Height: 37mm
Installation Hole Distance: 94mm
Maximum Opening: 65mm
Jaw Width: 65mm
Jaw Height: 20mm
Screw Diameter: 13.5mm
Net Weight: 1.3kg
How to Install:
1. Take out all the items in the package (one vise + four sets of bolts)
2. Place the vise on the console horizontally, and the screw rod is perpendicular to the edge of the console
3. Use the drilling tool to punch holes in the four corners of the bench vise
4. Rotate the bolts into the four cavities
5. Tighten the bolts to fix the bench vise and use it
Instructions:
1. Rotate the screw handle to separate the jaws
2. Place the item to be sanded in the center of the jaws
3. Rotate the screw handle to make the jaws fix the itemUser Target Audience:
Holding wood: sawing wood without loosening or slipping
Holding metal: Grinding metal has a strong bite
Holding glass: cutting glass securely
MarsHopper 2.5″ Versatile Universal Bench Vise, Quick Adjust Heavy Duty Cast Steel Drill Vice Bench Clamp Fixed Base for Woodworking, Glass Cutting, Steel Grinding
$51.99
- Overall Quenching: The whole bench vise is made of high-quality cast iron, and then undergoes quenching heat treatment, which makes the bench vise higher in hardness and toughness, and greatly prolongs its service life.
- Carbon Steel Jaws: The jaws are made of carbon steel material, and the clamping surface is embossed and anti-skid, which makes the clamping force more stable, the items are not easy to shake, and the effect is better!
- Bold Lead Screw: The turning lead screw is made of 45 steel, with excellent wear resistance and corrosion resistance; thick trapezoidal thread design, faster rotation and displacement, and strong locking; 180 rotatable crank handle, easy to rotate and flexible to adjust .
- Fixed Design: The base is fixed with double guide rails, which will not slide easily, and the positioning is more accurate; the slider tray has excellent smoothness, and the push is more stable, saving time and effort.
- Service Guarantee: 100% satisfaction guarantee, we provide you with high-quality after-sales service, as long as you have any dissatisfaction, please feel free to contact us, we will provide you with a 7-day worry-free return!
In stock
Additional information
| Weight | 1.3 kg |
|---|---|
| Brand | MarsHopper |
| EAN | 0794775045051 |
| UPC | 794775045051 |
