Features:
1.7″ color TFT LCD with sensitivity touch panel. No radiation, low power consumption.
2.Infrared LEDs for night vision,more convenient.
3.Rainproof cover design, anti oxidative Outdoor Unit with piano bakes lacquer panel.
4.25 kinds of rings for selection.
5.Piano bakes lacquer panel design on indoor unit, more fashionable and luxury.
6.Hands free intercom,one-button touch makes perfect experience.
7.Support maximum 1 outdoor unit with 4 indoor units
8.Support 2000 ID cards unlock, passwords unlock,remote controls unlock.
9.Embedded ‘IR-Cut Filter’ provides Enhanced Picture & Color Quality
Specifications:
1.Screen: 7″ TFT
2.Resolution: 960 * 480
3.Camera: 1/3″ HD 1000 TV Line
4.Camera lens: 3.6mm
5.Camera viewing angle: 92 degrees
6.Infrared LED: 6 pcs
7.Infrared lighting distance approximate : 2 meters
8. Support 2000 ID cards unlock,2000 passwords unlock,100 remote controls unlock.
9.Call duration time: 120 Seconds
10.Monitor duration time: 60 Seconds
11.Power consumption: Static state <0.5W, calling <10W
12.Power output: DC15V 2A
13.Effective distance: 200M(6×0.75M2)
14.Indoor monitor: 225 * 128 * 20m
15.Outdoor camera: 155 * 95 * 55mm
Electric Strike Lock NO:
1.Holding 500kg
2. Aluminum, Stainless Steel Bolt
3. Testing to 1000000 cycles
4. Lock Size: 150Lx39.5Wx34H(mm)
5. lt structure: Stainless Steel
Package includes:
1 * Outdoor camera
1 * Indoor monitor
1 * AC adapter
1 * 5m 6-core Connection cable
2 * 2-core Connection cable
5 *125KHz RFID Cards
1 * Electric Strike Lock
1 * Exit Button
1 * Remote Control
1 * Package of screws
1 * User manual - English
