The P Series is ideal for higher education classrooms, corporate boardrooms and rental where bright, sharp images are required. The NEC P554U includes advanced installation features such as horizontal & vertical lens shift and HDBaseT connectivity that provide greater installation flexibility. Adding horizontal & vertical keystone correction along with cornerstone and pincushion adjustment ensures the image will be square on the screen even if installation challanges exist. The long life lamp reduces maintenance and lowers total cost of ownership.
-Built-in display: N Ports & interfaces
-VGA (D-Sub) ports quantity: 2 -HDMI ports quantity: 2 -Composite video in: 1 -DVI port: N -Ethernet LAN (RJ-45) ports: 1 -USB 2.0 ports quantity: 1 -Audio (L,R) in: 1 -RS-232 ports: 1 -HDMI connector type: Full-size -HDBaseT port: Y -PC Audio in: Y -AC (power) in: Y -PC Audio out: Y Lens system
-Focal length range (f-f): 17.2 – 27.7 mm -Focus: Manual -Aperture range (F-F): 1.5 – 2.08 -Horizontal lens shift range: -15 – 15% -Vertical lens shift range: 0 – 55% -Throw ratio: 1.2 – 2.0:1 Weight & dimensions
-Weight: 4.8 kg -Width: 420 mm -Depth: 329 mm -Height: 141 mm Power
-Power source: AC -Power consumption (typical): 457 W -Power consumption (standby): 2 W -Power consumption (PowerSave): 0.14 W -AC input voltage: 100 – 240 -AC input frequency: 50/60 -Power consumption (economy mode): 286 W -Auto power off: Y Operational conditions
-Operating temperature (T-T): 5 – 40 °C -Storage temperature (T-T): -10 – 50 °C -Operating relative humidity (H-H): 20 – 80% Networking
-Ethernet LAN: Y -Wi-Fi: N -Ethernet LAN data rates: 10,100 Mbit/s Projector
-Projector brightness:
