Notes:
★ This product uses POE power supply and requires an external 802.3AF standard 48V POE switch.
★ This camera defaults to 5MP & H.265, if your NVR doesn’t support 5MP or H.265, you can change our camera to 1080P (2MP) and H.264.
★ The IP camera will generate more heat, and the casing of this camera is small, so after you operate the camera for a while, you will feel the camera is very hot. And don’t worry, it’s normal and safe, I hope you understand.
☆ HD 2880*1616P resolution 1/3” CMOS sensor
☆ 5MP 6-22mm zoom lens
☆ Support POE, there is also an auxiliary power interface, which can be used as a non-POE camera
☆ Also supports H.264 encoding, so it can be compatible with both H.264 and H.265 devices
☆ Support web interface of IE6.0 and above browsers
☆ P2P remote viewing
☆ Support motion detection, email alarm function
☆ Support iPhone, Android smart phone
☆ Mini camera design
☆ Metal shell
camera
Model: I712-2-P-HS
Resolution: 2880 x 1616P 5.0 megapixel camera
Sensor: FH8852V200+GC5053
Minimum illumination: 0.01Lux @(F1.2, AGC ON)
Compression format: H.264 / H.265
Output compression rate: 128 Kbps ~ 8Mbps
Frame rate: 25fps
Lens: 6-22mm zoom lens
NVR O nviif port: 80
Lens mount type: M12
Compression format: H.265/H.264
Storage: NVR or PC
IP address: dynamic (default)/static
Intelligent alarm: motion detection, email alarm
Supported protocols: HTTP, TCP/IP, RTSP, RTP, UPNP, SMTP, DHCP, DDNS, DNS, FTP, NTP
Ethernet: 10M/100M mbps Ethernet (RJ-45)
general
Operating temperature: -25°C~60°C
Working humidity: 10%~90%
Power supply: POE
POE standard: 802.3af
Dimensions (cm): 5.6 x 4.6 x 6.3cm
Weight: 0.25kg
Package Contents:
1 x camera
1 x User Manual
1 x screw set
